Setting up Notes SMTP MTA

Introduction

While the SMTP MTA component was an add-on in Notes/Domino 4.5, it is now part of Notes 4.6.x. If you didn't select it while installing the server originally, re-launch an install, and select SMTP MTA to be installed.

Basically, you just need to create a directory where incoming and ougoing (SMTP.BOX) messages will be handled. Once SMTP MTA is installed, create or modifiy the documents below, and run SMTP MTA.

Server Settings

Public Name & Address Book (PNAB) | Server section | Connections section: SERVER CONNECTION: AcmeSrv/ACME

Basics

Connection type:

SMTP

Usage priority:

Normal

Source server:

AcmeSrv/ACME

Destination server:



Connect via:

Direct connection

Destination domain:

Internet





Relay host:



Scheduled Connection

Routing and Replication

Connection:

ENABLED

Tasks:

SMTP Mail Routing

Call at times:

08:00 AM - 10:00 PM each day

Route at once if:

5 messages pending

Repeat interval of:

360 minutes

Routing cost:

1

Days of week:

Sun, Mon, Tue, Wed, Thu, Fri, Sat



PNAB | Server section | Domain section: DOMAIN: *.*

Basics



Restrictions



Domain type:

Foreign SMTP Domain

Allow mail only from domains:




Deny mail from domains:



Messages Addressed to:



Should be Routed to:



Internet Domain:

*.*

Domain name:

Internet


or,




Internet host:



 PNAB | Server section | Domain section: DOMAIN: AGDSGlobal

Basics



Members



Domain type:

Global Domain

Notes domains and aliases:

AGDS

Global domain name:

AGDSGlobal

Alias separator character:

=

Global domain role:

SMTP MTA



Use as default Global Domain (for use with all Internet protocols except HTTP):

Yes



SMTP Address Conversion



X.400 Address Conversion



Outbound mail restriction:

Unrestricted

Outbound mail restriction:

Restrict to global domain

Address format:

Name and Address

Country name:



Internet domain suffix:

AcmeSrv.acme.com

ADMD name:

(ADMD = single space)

Internet address lookup:

If disabled or no match,

Disabled

convert as follows:

PRMD name:



Local part formed from:

Full name

Notes domain attribute:

None

Notes domain(s) included:

All

DDA type:

LD

Notes domain(s) position:

Left of '@'



Notes domain separator:

% - percent sign



Address example:

"Jane M. Doe" <JMD%dom1%dom2%dom3@acme.com>



 PNAB | Server section | Server section : Change the current server's settings in the Internet Message Transfer Agent (SMTP MTA): SERVER: AcmeSrv/ACME

General



Control



Global domain name:

AGDSGlobal

Poll for new messages every:

60 seconds

Fully qualified Internet host name:

AcmeSrv.acme.com

MTA work path:

F:\SRV\SMTPTMP

MTA administrator:

Frederic Faure

Log level:

Normal


Enable daily housekeeping:
